BspCentral Class Reference

#include <BspCentral.hpp>

Collaboration diagram for BspCentral:

[legend]List of all members.

Public Member Functions
	BspCentral (Config &config)
void	registerRemoteIor (int pid, string ior)
void	takeYourPid (int pid)
void	waitGlobalInit ()
void	initSlave (string processZeroIor)
int	getPid ()
void	setPid (int pid_)
void	setTotalNumProcs (int numProcs)
int	getTotalNumProcs ()
string	getIor ()
void	bspPut (int pid, void *src, void *dst, int offset, int nBytes)
void	bspSynch ()
void	bspSynchDone ()
void	bspLocalSynch ()
void	addPendingPut (const BspPut &bspPut)
void	addPendingRegistration (void *ident, int size)
void	addPendingDeregistration (void *ident)
void	bspEnd ()
void	bspGet (int pid, void *src, int offset, void *dst, int nBytes)
void	bspGetRequest (const BspGetRequest &request)
void	bspGetReply (const BspGetReply &reply)
void	bspGetReplyFowarder (const int &pid, const BspGetReply &reply)
Private Member Functions
int	getNextPid ()
string	getIor (int taskNum)
string	getTaskId (int taskNum)
Private Attributes
BspProxyStubPool	stubPool
std::map< int, std::string >	tasks
std::map< int, std::string >	iors
int	myPid
int	totalNumProcs
GuardedVariable< int >	superstep
GuardedVariable< int >	synchedProcecess
GuardedVariable< int >	pids
DrmaManager	drmaManager
pthread_mutex_t	bspSynchLock
Condition	globalInitDone
Condition	synchDone

---

Detailed Description

BspCentral - Encapsulates BSP logic.

BspCentral contais methods needed by a BSP application. It contains a server side, represented by BspProxyImpl, and a client side implemented by BspProxyStubPool. It also implements the methods defined by BspProxy and fowarded by BspProxyImpl.

Author:

Andrei Goldchleger

Date:

november/2003

---

Constructor & Destructor Documentation

BspCentral::BspCentral (  Config &  config  )

Constructs a BspCentral object Parameters: config  - Configuration parameters such as ORB & IDL path

---

Member Function Documentation

void BspCentral::addPendingDeregistration (  void *  ident  )

Deregister the LAST registration of a given memory address Parameters: ident  - the memory address of the registration to be removed

void BspCentral::addPendingPut (  const BspPut &  bspPut  )

Adds a pending remote bsp_put request to the DrmaManager Parameters: bspPut  - the BspPut representing the put

void BspCentral::addPendingRegistration (  void *  ident, int  size )

Registers a memory area as globally accessible to all BSP tasks Parameters: ident  - Memory address to be registered size  - The size of the memory area being registered

void BspCentral::bspEnd (   )

FIXME Uninplemented

void BspCentral::bspGet (  int  pid, void *  src, int  offset, void *  dst, int  nBytes )

Implements the bsp_get method. Allows the local task to read from memory from a remote process. Parameters: pid  - The BSP process ID from where memory contents will be read src  - Memory address from where data will be copied offset  - Offset that will be added to the source address to determine the starting position from where data will be copied dst  - The destination address to were data will be written nBytes  - Number of bytes to be read

void BspCentral::bspGetReply (  const BspGetReply &  reply  )

Called by another BSP task in order to reply to one of our bspGetRequets Parameters: reply  - Contains information regarding the reply

void BspCentral::bspGetReplyFowarder (  const int &  pid, const BspGetReply &  reply )

Called by DrmaManager in order to reply to a bspGetRequest originated from a remote process Parameters: pid  - The BSP process ID of the process that issued the request reply  - Information suach as the memory contents to be copied to the remote task, destination address, etc...

void BspCentral::bspGetRequest (  const BspGetRequest &  request  )

Called by another BSP task in order to request the contents of a given memory area. Parameters: request  - Contains information regarding the request

void BspCentral::bspLocalSynch (   )

Indicates that the local BSP task reached a synchronization barrier and is awaiting for global synchronization

void BspCentral::bspPut (  int  pid, void *  src, void *  dst, int  offset, int  nBytes )

The implementation of the bsp_put operation. Allows a BSP task to write on the address space of a task. Parameters: pid  - The BSP process ID of the remote task on which bsp_put is going to be invoked src  - The local address from which memory contents will be copied to the remote BSP task dst  - The local address that will be translated to a logical BSP addressm, which is unique to all BSP tasks offset  - an offset from src that will hold when copying the memory area to the remote BSP task nBytes  - the number of bytes to be copied from src + offset to dst

void BspCentral::bspSynch (   )

Called on Process Zero to indicate that a given process reached the barrier synchronization.

void BspCentral::bspSynchDone (   )

Called by process zero on each remote BSP task to indicate that the current barrier synchronization is complete.

string BspCentral::getIor (   )

Gets the IOR of the local process

string BspCentral::getIor (  int  taskNum  )  [private]

Gets the IOR of a given task Parameters: taskNum  - PID of a BSP task

int BspCentral::getNextPid (   )  [private]

Returns the next BSP PID that should be attributed to a BSP task.

int BspCentral::getPid (   )  [inline]

Return the BSP PID of the local task

string BspCentral::getTaskId (  int  taskNum  )  [private]

Gets the BspProxyStubPool ID of a given task Parameters: taskNum  - PID of a BSP task

int BspCentral::getTotalNumProcs (   )  [inline]

Gets the total number of tasks in the BSP application

void BspCentral::initSlave (  string  processZeroIor  )

Initializes the BspCentral when the task in question is a slave, that is, not the process zero. Parameters: processZeroIor  - IOR of process zero

void BspCentral::registerRemoteIor (  int  pid, string  ior )

Register the IOR of a remote BSP task. This method encapsulate the logic of the method defined in BspProxy IDL interface and fowarded by BspProxyImpl Parameters: pid  - the BSP PID of the remote task ior  - the IOR of the emote task

void BspCentral::setPid (  int  pid_  )  [inline]

Sets the BSP PID of the local task

void BspCentral::setTotalNumProcs (  int  numProcs  )  [inline]

Sets the total number of tasks in the BSP application

void BspCentral::takeYourPid (  int  pid  )

Receives a PID from process zero. This method encapsulate the logic of the method defined in BspProxy IDL interface and fowarded by BspProxyImpl. Parameters: pid  - the new BSP PID for this task

void BspCentral::waitGlobalInit (   )

Blocks until initialization is complete, that is all tasks know all the PIDs and IORs of each other

---

Member Data Documentation

pthread_mutex_t BspCentral::bspSynchLock [private]

Lock to avoid race conditions between local and remote synchronization requests. Relevant only to process zero

DrmaManager BspCentral::drmaManager [private]

DrmaManager object. Responsible for DRMA operations

Condition BspCentral::globalInitDone [private]

Indicates Wether or not global initialization is complete, that is, each tasks has its pid and knows the IORs of each other

std::map<int, std::string> BspCentral::iors [private]

iors of the remote tasks

int BspCentral::myPid [private]

PID of this BSP task

GuardedVariable<int> BspCentral::pids [private]

Last pid atributted to a BSP tast. Relevant to process zero only.

BspProxyStubPool BspCentral::stubPool [private]

The stubPool contains proxies for each of the other BSP tasks

GuardedVariable<int> BspCentral::superstep [private]

The current superstep of the BSP application

Condition BspCentral::synchDone [private]

Indicate wether or not a bsp_synch is complete

GuardedVariable<int> BspCentral::synchedProcecess [private]

Number of tasks that called bsp_synch. Relevant to process zero only.

std::map<int, std::string> BspCentral::tasks [private]

Ids for proxy retrieval from the stubPool

int BspCentral::totalNumProcs [private]

Total number of tasks in the BSP program

---

The documentation for this class was generated from the following files:

• BspCentral.hpp
• BspCentral.cpp

---
